ANR 7.125-8.5GHz 42.9dBi 8' Parabolic Dish CPR112G
(No reviews yet)
Write a Review
Write a Review
ANR
ANR 7.125-8.5GHz 42.9dBi 8' Parabolic Dish CPR112G
$5,440.00
- Brand
- ANR
- SKU:
- PL8-71W-PXA
- Weight:
- 920.00 LBS
- Shipping:
- Calculated at Checkout
CommScope 7.125-8.5 GHz single polarized wide band antenna. 42.9 dBi mid band. 1.1 degree beamwidth, f/b ratio 52dB. CPR112G connector. Molded Gray Radome.
| Specific Frequency | 7.125-8.5 GHz |
| Diameter | 8 ft |
| Gain, Low | 42.3 dBi |
| Gain, Middle | 42.9 dBi |
| Gain, High | 43.6 dBi |
| Polarization | Single |
| Horizontal Beamwidth | 1.1 deg |
| Minimum Front Back Ratio | 52 dB |
| XPD | 30 dB |
| Maximum VSWR | 1.10:1 |
| Flange Type | CPR112G |
| Maximum Rated Wind Velocity | 124 |
| Item Height | 106.5 in |
| Item Length | 64.25 in |
| Item Width | 106.5 in |
| Item Weight | 365 lb |
