UBIQUITI AM-5AC22-45

UBIQUITI AM-5AC22-45

5GHZ AIRMAX SECTOR ANTENNA, DUAL-POL 45-DEGREE 22DBI

airMAX ac 2x2 BaseStation Sector Antenna

The airMAX ac Sector Antennas feature significant advances in scalability, noise isolation and beam performance to complement the Rocket5ac radios in Point-to-MultiPoint (PtMP) networks. They are compatible with RocketM5 models; however, optimal performance requires the Rocket5ac.

• Frequency Range: 5.10-5.85 GHz
• Gain: 22dBi
• Polarization: Dual Linear
• Cross-pol Isolation: 25dB min
• Max VSWR: 1.5:1
• Hpol Beamwidth (6dB): 45 deg.
• Vpol Beamwidth (6dB): 45 deg.
• Elevation Beamwidth: 4 deg.
• Electrical Downtilt: 2 deg.
• ETSI Specification: EN 302 326 DN2
• Dimensions: 29.53 x 8.47 x 3.70in (750 x 215 x 94mm)
• Weight: 13.23 lbs (6.0kg)
